Deep well Pump
Submersible Borehole Pump
5SNM
Product Model
Application Scenario:
Private House
Garden
Agriculture/ Irrigation
Professional Certification:
Product name: 5SNM Series
Operating Limit
Liquid temperature up to +35°C
Ambient temperature up to +40°C
Continuous duty
Maximum sand content 0.15%
Minimum well diameter :-4″ for 100SCm pumps ;-5″for 125SCm pumps
Motor Information
Two-pole induction motor
Single phase, 220-240V
Three Phase 380-415V
Insulation class: F
Protection class: IP68
Material Description
External case：Stainless steel AISI201
Discharge head：Stainless steel AISI201
Diffuser：Plastic PC
Impeller：Plastic PPO
Pump shaft：Stainless steel AISI304
Oil chamber：Aluminum/Brass
